HP Sprocket Studio App - Using the HP Sprocket App

This document is for the HP sprocket app.
The HP sprocket app is the main software to use with your Sprocket. With this app, you can take and edit photos, and then send the print jobs to your Sprocket.
 The HP sprocket app icon

Step 1: Install the HP sprocket app

Here’s how to connect the Sprocket app to your printer once it is downloaded to your mobile device:
  1. To connect the Sprocket app via Wi-Fi®:
  2. Press and hold the power button to turn on the printer. The power LED indicator will light up when fully powered on.
  3. Open the Sprocket app. Then, select the main menu in the top corner of the screen.
  4. Select Manage Printers. Then, tap Add New Printer.
  5. Select the new printer “Studio Plus” from the list. Then, agree to connect your printer via Bluetooth.
  6. Now after you select printer, you must enter Wi-Fi® credentials to configure printer on yourWi-Fi® network.
  7. note:
    Your mobile device should stay connected on the same Wi-Fi® network. Printer is only compatible with 2.4 GHz Wi-Fi® network.
  8. After entering credentials, confirm and wait for your printer to connect. The Wi-Fi® LEDindicator will blink showing that printer is connecting. The light will turn solid when printeris fully connected.
  9. note:
    After connection is complete, you can go to the app’s settings and see what Wi-Fi network your printer is connect to.
  10. To connect the Sprocket app via Hotspot Mode:
  11. Press and hold the power button to turn on the printer. The power LED indicator will light up when fully powered on.
  12. Open the Sprocket app. Then, select the main menu in the top corner of the screen.
  13. Select Manage Printers. Then, tap Add New Printer.
  14. Select the new printer “Studio Plus” from the list. To connect printer via Hotspot mode, select “No Network Available” in the Connect Printer to Wi-Fi® menu.
  15. Then, open your Wi-Fi® list in your mobile device's settings. Select your printer from the list.
  16. Type the password for the printer. The password will be the serial number on the label of your printer.
  17. Next, wait for your printer to connect. The Wi-Fi® LED indicator will blink showing that printer is connecting. The light will turn solid when printer is fully connected.
  18. note:
    After connection is complete, you can go to the app’s settings and confirm that your printer is connected in Hotspot Mode.

Step 2: Print photos

Print photos using one of several available ways.

Frequently asked questions (FAQs)

Review these frequently asked questions.
